Acoustic Lighting Focus

For spaces that require maximum focus, this acoustic lighting fixture, of the same name, beautifully marries illumination and acoustics. The high-tech lens ensures an almost invisible light source and offers a non-intrusive design that lets thoughts and ideas dominate the space.

  • focus1_slider
  • focus2_slider
  • Slider3

Available colours

Quiet Neutrals

These shades work in harmony with natural textural materials and soften industrial environments. From light to dark and cool to warm, these are the foundations of any scheme where longevity and a mood of calm is desired.

Learn more

Warm Naturals

Combinations of lighter toned neutrals and pinks have a gently soothing and restorative effect while the more saturated hues make perfect environments for relaxation.

Learn more

Living Greens

From the cool greens of forests to the yellowed aspect of young wheat, we see Living Greens breathing life into indoor spaces, and an essential palette for the future. Use in tonal layers brings the depth and diversity of green, while a single note can provide an amplifying backdrop to a biophilic space.

Learn more

Elemental Blues

These blues work perfectly both as familiar single hues and in effortless tonal layers to create an immersive environment for focus or restoration.

Learn more

Soothing Pastels

With tonal duos of pink and blue and green, this perfectly balanced group is designed for peaceful plays on light and shade and playful contrast. While the lightest tones have a dreamlike quality, their deeper counterparts add a subtle grounding.

Learn more

Elegant Darks

While colour can create a mood, it is the depth or lightness of a hue that truly defines the emotion. While each hue has the strength to stand alone, beautiful effects can be achieved with harmonized pairs.

Learn more

Energetic Brights

There are no rules here with endless possibilities for clashing contrasts or surprising highlights. For a sophisticated use of energetic colour, take a single hue and colour match contrasting textiles and solid surfaces.

Learn more

Primary Play

The primary story happens when all three main colours are used together, with varied proportions creating differing moods. As with the Energetic Brights palette, combine with coordinating-coloured textiles and solid surfaces.

Learn more

Still not sure which colour looks best for your amazing project?

Colours on the screen may differ from the real material. We will gladly send you a free sample box so that you can decide at your comfort which colour suits best for your next project.

Order a free sample box

Technical Data

Looking for different sizes and shapes?
All our products are customizable to your exact needs.

Contact our Design Studio

Details

Metric

Imperial

Article number
721.24.10.000.00

Technical specifications
Length
1800mm 70.86"
Width
2400mm 94.48"
Height
75mm 2.95"
Voltage
220 - 240 V 110- 120 V
Dimming
DALI DALI
Light distribution
Direct (66°), developed by Bartenbach Direct (66°), developed by Bartenbach
Diffuser
Microprism Microprism
Total power
28W 28W
Colour temperature (CCT)
4000K 4000K
3000K on request 3000K on request
Luminus flux of the luminaire
2880 lm 2880 lm
Luminous flux of the light source
3800 lm 3800 lm
Colour renderingindex (CRI)
90 90
Case colour
Black Black
Ingress protection
IP20 IP20
Protection class
I I
Life Span
> 50'000 h (L70 B50) > 50'000 h (L70 B50)
Colour Consistency
SDCM3 SDCM3
Unified Glare Rating
UGR < 16 UGR < 16

Acoustic material

Material description

ARCHISONIC® is a high-performance sustainable acoustic absorber made from up-cycled plastic bottles which is Cradle to Cradle certified and LEED accredited. ARCHISONIC® is manufactured at the highest quality standards, yet slight colour and surface deviations caused by the high degree of recycled fiber are an inevitable part of the product characteristics and do not claim warranty services. Material varies in colour when shown in monitor or in print. Please request a free material sample to verify colours.

Material composition

100% PET (min. 60% post-consumer)

Fire Test

DIN EN 13501-1 B-s1, d0
ASTM E-84 Class A

VOC emission

CDPH 01350 Pass
ISO 16000 (CDPH/EHLB/Standard Method V1.2.)
EN 16516

Colour fastness

EN ISO 105-B02, A1 Grade 6

Sound absoprtion

DIN ISO 11654

24mm
aw 0.55 (no airgap)
aw 0.65 (50 mm / 2” air gap)
aw 0.90 (100 mm / 4” air gap)
aw 0.95 (200 mm / 8” air gap)
aw 0.95 (300 mm / 11” air gap)

12mm
aw 0.30 (no air gap)

Material reutilisation

ARCHISONIC® 24 mm:
88 plastic bottles/m2

ARCHISONIC® 12 mm:
53 plastic bottles/m2

Environmental

Cradle to Cradle Certified™
Product qualifies for LEED v4 specifications on VOC emissions in LEED EQ credit(Low-emitting products)
Supported by Climate KIC

Details

Metric

Imperial

Article number
721.24.11.000.00

Technical specifications
Length
1800mm 70.86"
Width
1800mm 70.86"
Height
75mm 2.95"
Voltage
220 - 240 V 110- 120 V
Dimming
DALI DALI
Light distribution
Direct (66°), developed by Bartenbach Direct (66°), developed by Bartenbach
Diffuser
Microprism Microprism
Total power
28W 28W
Colour temperature (CCT)
4000K 4000K
3000K on request 3000K on request
Luminus flux of the luminaire
1440 lm 1440 lm
Luminous flux of the light source
1900 lm 1900 lm
Colour renderingindex (CRI)
90 90
Case colour
Black Black
Ingress protection
IP20 IP20
Protection class
I I
Life Span
> 50'000 h (L70 B50) > 50'000 h (L70 B50)
Colour Consistency
SDCM3 SDCM3
Unified Glare Rating
UGR < 16 UGR < 16

Acoustic material

Material description

ARCHISONIC® is a high-performance sustainable acoustic absorber made from up-cycled plastic bottles which is Cradle to Cradle certified and LEED accredited. ARCHISONIC® is manufactured at the highest quality standards, yet slight colour and surface deviations caused by the high degree of recycled fiber are an inevitable part of the product characteristics and do not claim warranty services. Material varies in colour when shown in monitor or in print. Please request a free material sample to verify colours.

Material composition

100% PET (min. 60% post-consumer)

Fire Test

DIN EN 13501-1 B-s1, d0
ASTM E-84 Class A

VOC emission

CDPH 01350 Pass
ISO 16000 (CDPH/EHLB/Standard Method V1.2.)
EN 16516

Colour fastness

EN ISO 105-B02, A1 Grade 6

Sound absoprtion

DIN ISO 11654

24mm
aw 0.55 (no airgap)
aw 0.65 (50 mm / 2” air gap)
aw 0.90 (100 mm / 4” air gap)
aw 0.95 (200 mm / 8” air gap)
aw 0.95 (300 mm / 11” air gap)

12mm
aw 0.30 (no air gap)

Material reutilisation

ARCHISONIC® 24 mm:
88 plastic bottles/m2

ARCHISONIC® 12 mm:
53 plastic bottles/m2

Environmental

Cradle to Cradle Certified™
Product qualifies for LEED v4 specifications on VOC emissions in LEED EQ credit(Low-emitting products)
Supported by Climate KIC

Details

Metric

Imperial

Article number
824.14.00.303.00

Technical specifications
Length
295mm 11.61"
Width
60mm 2.36"
Height
75mm 2.95"
Voltage
220 - 240 V 110- 120 V
Dimming
DALI DALI
Light distribution
Direct (66°), developed by Bartenbach Direct (66°), developed by Bartenbach
Diffuser
Microprism Microprism
Total power
28W 28W
Colour temperature (CCT)
4000K 4000K
3000K on request 3000K on request
Luminus flux of the luminaire
1440 lm 1440 lm
Luminous flux of the light source
1900 lm 1900 lm
Colour renderingindex (CRI)
90 90
Case colour
Black Black
Ingress protection
IP20 IP20
Protection class
I I
Life Span
> 50'000 h (L70 B50) > 50'000 h (L70 B50)
Colour Consistency
SDCM3 SDCM3
Unified Glare Rating
UGR < 16 UGR < 16

Acoustic material

Material description

ARCHISONIC® is a high-performance sustainable acoustic absorber made from up-cycled plastic bottles which is Cradle to Cradle certified and LEED accredited. ARCHISONIC® is manufactured at the highest quality standards, yet slight colour and surface deviations caused by the high degree of recycled fiber are an inevitable part of the product characteristics and do not claim warranty services. Material varies in colour when shown in monitor or in print. Please request a free material sample to verify colours.

Material composition

100% PET (min. 60% post-consumer)

Fire Test

DIN EN 13501-1 B-s1, d0
ASTM E-84 Class A

VOC emission

CDPH 01350 Pass
ISO 16000 (CDPH/EHLB/Standard Method V1.2.)
EN 16516

Colour fastness

EN ISO 105-B02, A1 Grade 6

Sound absoprtion

DIN ISO 11654

24mm
aw 0.55 (no airgap)
aw 0.65 (50 mm / 2” air gap)
aw 0.90 (100 mm / 4” air gap)
aw 0.95 (200 mm / 8” air gap)
aw 0.95 (300 mm / 11” air gap)

12mm
aw 0.30 (no air gap)

Material reutilisation

ARCHISONIC® 24 mm:
88 plastic bottles/m2

ARCHISONIC® 12 mm:
53 plastic bottles/m2

Environmental

Cradle to Cradle Certified™
Product qualifies for LEED v4 specifications on VOC emissions in LEED EQ credit(Low-emitting products)
Supported by Climate KIC

Developed in partnership with PROLICHT

All our lighting solutions are developed in partnership with the Austrian experts PROLICHT. Together we develop lighting solutions with the highest standards for professional needs. While Prolicht is responsible for the technology, we develop the design and the acoustic performance.
