Acoustic Lighting Circ
It's a product that brilliantly demonstrates our specialty in custom luminaire design. Choose from one of our 32 colours and even perfectly match the pattern of the luminaire shade to the planned interior.
Developed with PROLICHT
Available in 32 colours
Individual V-cuts
UL certified
Circ | 432 Pacific Ocean
product.AR
Augmented Reality lets you explore our products from every angle and see how they look in a space. Drag and move, or scan the QR code to enter the full-screen AR experience on your mobile device.
Available in all 32 colours
Quiet Neutrals
These shades work in harmony with natural textural materials and soften industrial environments. From light to dark and cool to warm, these are the foundations of any scheme where longevity and a mood of calm is desired.
Warm Naturals
Combinations of lighter toned neutrals and pinks have a gently soothing and restorative effect while the more saturated hues make perfect environments for relaxation.
Living Greens
From the cool greens of forests to the yellowed aspect of young wheat, we see Living Greens breathing life into indoor spaces, and an essential palette for the future. Use in tonal layers brings the depth and diversity of green, while a single note can provide an amplifying backdrop to a biophilic space.
Elemental Blues
These blues work perfectly both as familiar single hues and in effortless tonal layers to create an immersive environment for focus or restoration.
Soothing Pastels
With tonal duos of pink and blue and green, this perfectly balanced group is designed for peaceful plays on light and shade and playful contrast. While the lightest tones have a dreamlike quality, their deeper counterparts add a subtle grounding.
Elegant Darks
While colour can create a mood, it is the depth or lightness of a hue that truly defines the emotion. While each hue has the strength to stand alone, beautiful effects can be achieved with harmonized pairs.
Energetic Brights
There are no rules here with endless possibilities for clashing contrasts or surprising highlights. For a sophisticated use of energetic colour, take a single hue and colour match contrasting textiles and solid surfaces.
Primary Play
The primary story happens when all three main colours are used together, with varied proportions creating differing moods. As with the Energetic Brights palette, combine with coordinating-coloured textiles and solid surfaces.
Order a free sample box
Discover ARCHISONIC® Felt our high-performance
acoustic absorber. Get inspired by our 32 colour samples.
Get a quote
Get a quote for your own project or
find a representative in your area.
Technical Data
No matter what size or shape you need, we've got you covered. Our products are fully customisable to meet your exact specifications and preferences.
Details
Metric
Imperial
- Article number
- 726.24.20.000.00
- Technical specifications
-
Diameter1000mm 39.37"Thickness24mm 0.9"Height75mm 2.95"Voltage220 - 240 V 110- 120 VDimmingNot dimmable Not dimmable(DALI on request) (DALI on request)Light distributionDirect DirectDiffuserOpal Opal(Microprism on request) (Microprism on request)Total power18W 18WColour temperature (CCT)4000K 4000K(3000K on request) (3000K on request)Luminus flux of the luminaire2415 lm 2415 lmLuminous flux of the light source2910 lm 2910 lmColour renderingindex (CRI)90 90Case colourBlack BlackIngress protectionIP20 IP20Protection classI ILife Span> 50'000 h (L70 B50) > 50'000 h (L70 B50)Colour ConsistencySDCM3 SDCM3
Diagrams
1000x24x75mm
Acoustic material
- Material description
- Material composition
- Fire Test
- VOC emission
- Colour fastness
- Material reutilisation
- Environmental
ARCHISONIC® is a high-performance sustainable acoustic absorber made from up-cycled plastic bottles which is Cradle to Cradle certified and LEED accredited. ARCHISONIC® is manufactured at the highest quality standards, yet slight colour and surface deviations caused by the high degree of recycled fiber are an inevitable part of the product characteristics and do not claim warranty services. Material varies in colour when shown in monitor or in print. Please request a free material sample to verify colours.
100% PET (min. 60% post-consumer)
DIN EN 13501-1 B-s1, d0
ASTM E-84 Class A
CDPH 01350 Pass
ISO 16000 (CDPH/EHLB/Standard Method V1.2.)
EN 16516
EN ISO 105-B02, A1 Grade 6
ARCHISONIC® 24 mm:
88 plastic bottles/m2
ARCHISONIC® 12 mm:
53 plastic bottles/m2
Cradle to Cradle Certified™
Product qualifies for LEED v4 specifications on VOC emissions in LEED EQ credit(Low-emitting products)
Supported by Climate KIC
Acoustic performance
- Sound absorption
DIN ISO 11654
24mm
aw 0.55 (no airgap)
aw 0.65 (50 mm / 2” air gap)
aw 0.90 (100 mm / 4” air gap)
aw 0.95 (200 mm / 8” air gap)
aw 0.95 (300 mm / 11” air gap)
12mm
aw 0.30 (no air gap)
DWG
Technical Data Sheet
Details
Metric
Imperial
- Article number
- 726.24.17.000.00
- Technical specifications
-
Diameter1200 47.24"Thickness24mm 0.9"Height75mm 2.95"Voltage220 - 240 V 110- 120 VDimmingNot dimmable Not dimmable(DALI on request) (DALI on request)Light distributionDirect DirectDiffuserOpal Opal(Microprism on request) (Microprism on request)Total power18W 18WColour temperature (CCT)4000K 4000K(3000K on request) (3000K on request)Luminus flux of the luminaire2415 lm 2415 lmLuminous flux of the light source2910 lm 2910 lmColour renderingindex (CRI)90 90Case colourBlack BlackIngress protectionIP20 IP20Protection classI ILife Span> 50'000 h (L70 B50) > 50'000 h (L70 B50)Colour ConsistencySDCM3 SDCM3
Diagrams
1200x24x75mm
Acoustic material
- Material description
- Material composition
- Fire Test
- VOC emission
- Colour fastness
- Material reutilisation
- Environmental
ARCHISONIC® is a high-performance sustainable acoustic absorber made from up-cycled plastic bottles which is Cradle to Cradle certified and LEED accredited. ARCHISONIC® is manufactured at the highest quality standards, yet slight colour and surface deviations caused by the high degree of recycled fiber are an inevitable part of the product characteristics and do not claim warranty services. Material varies in colour when shown in monitor or in print. Please request a free material sample to verify colours.
100% PET (min. 60% post-consumer)
DIN EN 13501-1 B-s1, d0
ASTM E-84 Class A
CDPH 01350 Pass
ISO 16000 (CDPH/EHLB/Standard Method V1.2.)
EN 16516
EN ISO 105-B02, A1 Grade 6
ARCHISONIC® 24 mm:
88 plastic bottles/m2
ARCHISONIC® 12 mm:
53 plastic bottles/m2
Cradle to Cradle Certified™
Product qualifies for LEED v4 specifications on VOC emissions in LEED EQ credit(Low-emitting products)
Supported by Climate KIC
Acoustic performance
- Sound absorption
DIN ISO 11654
24mm
aw 0.55 (no airgap)
aw 0.65 (50 mm / 2” air gap)
aw 0.90 (100 mm / 4” air gap)
aw 0.95 (200 mm / 8” air gap)
aw 0.95 (300 mm / 11” air gap)
12mm
aw 0.30 (no air gap)
Details
Metric
Imperial
- Article number
- 726.24.18.000.00
- Technical specifications
-
Diameter1800mm 70.86"Thickness24mm 0.9"Height75mm 2.95"Voltage220 - 240 V 110- 120 VDimmingNot dimmable Not dimmable(DALI on request) (DALI on request)Light distributionDirect DirectDiffuserOpal Opal(Microprism on request) (Microprism on request)Total power18W 18WColour temperature (CCT)4000K 4000K(3000K on request) (3000K on request)Luminus flux of the luminaire2415 lm 2415 lmLuminous flux of the light source2910 lm 2910 lmColour renderingindex (CRI)90 90Case colourBlack BlackIngress protectionIP20 IP20Protection classI ILife Span> 50'000 h (L70 B50) > 50'000 h (L70 B50)Colour ConsistencySDCM3 SDCM3
Diagrams
1800x24x75mm
Acoustic material
- Material description
- Material composition
- Fire Test
- VOC emission
- Colour fastness
- Material reutilisation
- Environmental
ARCHISONIC® is a high-performance sustainable acoustic absorber made from up-cycled plastic bottles which is Cradle to Cradle certified and LEED accredited. ARCHISONIC® is manufactured at the highest quality standards, yet slight colour and surface deviations caused by the high degree of recycled fiber are an inevitable part of the product characteristics and do not claim warranty services. Material varies in colour when shown in monitor or in print. Please request a free material sample to verify colours.
100% PET (min. 60% post-consumer)
DIN EN 13501-1 B-s1, d0
ASTM E-84 Class A
CDPH 01350 Pass
ISO 16000 (CDPH/EHLB/Standard Method V1.2.)
EN 16516
EN ISO 105-B02, A1 Grade 6
ARCHISONIC® 24 mm:
88 plastic bottles/m2
ARCHISONIC® 12 mm:
53 plastic bottles/m2
Cradle to Cradle Certified™
Product qualifies for LEED v4 specifications on VOC emissions in LEED EQ credit(Low-emitting products)
Supported by Climate KIC
Acoustic performance
- Sound absorption
DIN ISO 11654
24mm
aw 0.55 (no airgap)
aw 0.65 (50 mm / 2” air gap)
aw 0.90 (100 mm / 4” air gap)
aw 0.95 (200 mm / 8” air gap)
aw 0.95 (300 mm / 11” air gap)
12mm
aw 0.30 (no air gap)
Details
Metric
Imperial
- Article number
- 726.24.20.000.60
- Technical specifications
-
Diameter1000mm 39.37"Thickness24mm 0.9"Height75mm 2.95"Voltage220 - 240 V 110- 120 VDimmingNot dimmable Not dimmable(DALI on request) (DALI on request)Light distributionDirect DirectDiffuserOpal Opal(Microprism on request) (Microprism on request)Total power18W 18WColour temperature (CCT)4000K 4000K(3000K on request) (3000K on request)Luminus flux of the luminaire2415 lm 2415 lmLuminous flux of the light source2910 lm 2910 lmColour renderingindex (CRI)90 90Case colourBlack BlackIngress protectionIP20 IP20Protection classI ILife Span> 50'000 h (L70 B50) > 50'000 h (L70 B50)Colour ConsistencySDCM3 SDCM3
- More information
-
Diagrams
1000x24x75mm, V-Cut
Acoustic material
- Material description
- Material composition
- Fire Test
- VOC emission
- Colour fastness
- Material reutilisation
- Environmental
ARCHISONIC® is a high-performance sustainable acoustic absorber made from up-cycled plastic bottles which is Cradle to Cradle certified and LEED accredited. ARCHISONIC® is manufactured at the highest quality standards, yet slight colour and surface deviations caused by the high degree of recycled fiber are an inevitable part of the product characteristics and do not claim warranty services. Material varies in colour when shown in monitor or in print. Please request a free material sample to verify colours.
100% PET (min. 60% post-consumer)
DIN EN 13501-1 B-s1, d0
ASTM E-84 Class A
CDPH 01350 Pass
ISO 16000 (CDPH/EHLB/Standard Method V1.2.)
EN 16516
EN ISO 105-B02, A1 Grade 6
88 plastic bottles/m2
ARCHISONIC® 12 mm:
53 plastic bottles/m2
Cradle to Cradle Certified™
Product qualifies for LEED v4 specifications on VOC emissions in LEED EQ credit(Low-emitting products)
Supported by Climate KIC
Acoustic performance
- Sound absorption
DIN ISO 11654
24mm
aw 0.55 (no airgap)
aw 0.65 (50 mm / 2” air gap)
aw 0.90 (100 mm / 4” air gap)
aw 0.95 (200 mm / 8” air gap)
aw 0.95 (300 mm / 11” air gap)
12mm
aw 0.30 (no air gap)
Details
Metric
Imperial
- Article number
- 726.24.17.000.60
- Technical specifications
-
Diameter1200 47.24"Thickness24mm 0.9"Height75mm 2.95"Voltage220 - 240 V 110- 120 VDimmingNot dimmable Not dimmable(DALI on request) (DALI on request)Light distributionDirect DirectDiffuserOpal Opal(Microprism on request) (Microprism on request)Total power18W 18WColour temperature (CCT)4000K 4000K(3000K on request) (3000K on request)Luminus flux of the luminaire2415 lm 2415 lmLuminous flux of the light source2910 lm 2910 lmColour renderingindex (CRI)90 90Case colourBlack BlackIngress protectionIP20 IP20Protection classI ILife Span> 50'000 h (L70 B50) > 50'000 h (L70 B50)Colour ConsistencySDCM3 SDCM3
Diagrams
1200x24x75mm, V-Cut
Acoustic material
- Material description
- Material composition
- Fire Test
- VOC emission
- Colour fastness
- Material reutilisation
- Environmental
ARCHISONIC® is a high-performance sustainable acoustic absorber made from up-cycled plastic bottles which is Cradle to Cradle certified and LEED accredited. ARCHISONIC® is manufactured at the highest quality standards, yet slight colour and surface deviations caused by the high degree of recycled fiber are an inevitable part of the product characteristics and do not claim warranty services. Material varies in colour when shown in monitor or in print. Please request a free material sample to verify colours.
100% PET (min. 60% post-consumer)
DIN EN 13501-1 B-s1, d0
ASTM E-84 Class A
CDPH 01350 Pass
ISO 16000 (CDPH/EHLB/Standard Method V1.2.)
EN 16516
EN ISO 105-B02, A1 Grade 6
ARCHISONIC® 24 mm:
88 plastic bottles/m2
ARCHISONIC® 12 mm:
53 plastic bottles/m2
Cradle to Cradle Certified™
Product qualifies for LEED v4 specifications on VOC emissions in LEED EQ credit(Low-emitting products)
Supported by Climate KIC
Acoustic performance
- Sound absorption
DIN ISO 11654
24mm
aw 0.55 (no airgap)
aw 0.65 (50 mm / 2” air gap)
aw 0.90 (100 mm / 4” air gap)
aw 0.95 (200 mm / 8” air gap)
aw 0.95 (300 mm / 11” air gap)
12mm
aw 0.30 (no air gap)
Details
Metric
Imperial
- Article number
- 726.24.18.000.60
- Technical specifications
-
Diameter1800mm 70.86"Thickness24mm 0.9"Height75mm 2.95"Voltage220 - 240 V 110- 120 VDimmingNot dimmable Not dimmable(DALI on request) (DALI on request)Light distributionDirect DirectDiffuserOpal Opal(Microprism on request) (Microprism on request)Total power18W 18WColour temperature (CCT)4000K 4000K(3000K on request) (3000K on request)Luminus flux of the luminaire2415 lm 2415 lmLuminous flux of the light source2910 lm 2910 lmColour renderingindex (CRI)90 90Case colourBlack BlackIngress protectionIP20 IP20Protection classI ILife Span> 50'000 h (L70 B50) > 50'000 h (L70 B50)Colour ConsistencySDCM3 SDCM3SDCM3
Diagrams
1800x24x75mm, V-Cut
Acoustic material
- Material description
- Material composition
- Fire Test
- VOC emission
- Colour fastness
- Material reutilisation
- Environmental
ARCHISONIC® is a high-performance sustainable acoustic absorber made from up-cycled plastic bottles which is Cradle to Cradle certified and LEED accredited. ARCHISONIC® is manufactured at the highest quality standards, yet slight colour and surface deviations caused by the high degree of recycled fiber are an inevitable part of the product characteristics and do not claim warranty services. Material varies in colour when shown in monitor or in print. Please request a free material sample to verify colours.
100% PET (min. 60% post-consumer)
DIN EN 13501-1 B-s1, d0
ASTM E-84 Class A
CDPH 01350 Pass
ISO 16000 (CDPH/EHLB/Standard Method V1.2.)
EN 16516
EN ISO 105-B02, A1 Grade 6
ARCHISONIC® 24 mm:
88 plastic bottles/m2
ARCHISONIC® 12 mm:
53 plastic bottles/m2
Cradle to Cradle Certified™
Product qualifies for LEED v4 specifications on VOC emissions in LEED EQ credit(Low-emitting products)
Supported by Climate KIC
Acoustic performance
- Sound absorption
DIN ISO 11654
24mm
aw 0.55 (no airgap)
aw 0.65 (50 mm / 2” air gap)
aw 0.90 (100 mm / 4” air gap)
aw 0.95 (200 mm / 8” air gap)
aw 0.95 (300 mm / 11” air gap)
12mm
aw 0.30 (no air gap)
Developed in partnership with PROLICHT
All our lighting solutions are developed in partnership with the Austrian experts PROLICHT. Together we develop lighting solutions with the highest standards for professional needs. While Prolicht is responsible for the technology, we develop the design and the acoustic performance.
Berry Consulting
Swiss Insurance Company
Bespoke solutions
We specialize in creating bespoke acoustic solutions tailored to your needs. Contact our Design Studio today for expert advice and personalised solutions that meet your exact specifications.
